K025
K025
Industry:
チラー
ヒートポンプ
リーファー/冷凍庫
廃熱回収
食品機器産業
製薬
半導体
油圧産業
工作機械
バイオテクノロジー
再生可能エネルギー
地域暖房
ボイラー
流体の冷却/加熱
データセンターインフラストラクチャ
プラスチック射出/ゴム押出機
エアコンプレッサ
ギアボックスの加熱/冷却
Application:
蒸発器
凝縮器
過熱器/過冷卻器
エコノマイザー
オイルクーラー
サブクーラー
ガスクーラー
Heat Load(up to)kW:
3.52
Plate Material:
SUS316
Brazing Material:
銅
Max number of plates(N):
60
Working Pressure:
30
Min test pressure(bar):
43
Max working temperature:
200
Max flow_rate:
80
Plate Heat Transfer Area:
0.012
Thickness(mm):
6.70+2.27*N
Weight(kg):
0.48+0.040*N
Connection-Male Thread(up to):
3/4"
Connection-Female Thread(up to):
1/2"
Connection-Solder(up to):
5/8"
L1(mm):
205
L2(mm):
172
W1(mm):
73
W2(mm):
42
