Data Center Liquid Cooling

The coolant distribution unit (CDU) for servers is the latest achievement of the company‘s dedication to heat managements. Foreseeing the raising of high density computing power in server clusters, the huge amount of heat generated requires efficient management to ensure the optimal operation temperature for servers. The CDU combining with plate heat exchangers is able to collect and recover waste heat simultaneously to preserve energy, and improves the power usage effectiveness (PUE) < 1.1.

We Provide Complete Immersion Liquid Cooling Solutions

  • Immersion liquid cooling server system (CDU) design, manufacturing, installation

  • Immersion type liquid cooling equipment control sub-automatic control software and hardware

  • Design, manufacture and installation of submerged liquid-cooled cabinets

  • Recommended immersion server manufacturer

    KAORI DEMO TANK

Solution: Immersion Liquid Cooling

(A)2kW Single Phase Immersion Cooling Demo Tank

  • Feature:
    (1) Ideal for indoor deployments at ambient temperature 25°C and below
    (2) 2U space for IT deployments
    (3) Max. cooling capacity up to 2kW indoor
  • Advantage:
    (1) No need for water chiller
    (2) Low noise level design, suitable for offices and laboratories
    (3) Cooling capacity equivalent to 1kW /U

  • Benefit:
    (1) Ideal for distributed 5G deployments
    (2) Dust free
    (3) High cooling efficiency in compact space
    (4) Extend lifespan for IT equipment
    (5) Zero water consumption

(B)7kW Single Phase Immersion Cooling Demo Tank

  • Feature:
    (1) Ideal for indoor deployments at ambient temperature 30°C and below
    (2) 4U space for IT deployments
    (3) Max. cooling capacity up to 7kW indoor
  • Advantage:
    (1) No need for water chiller
    (2) Low noise level design, suitable for offices and laboratories
    (3) Cooling capacity equivalent to 1.75kW /U

  • Benefit:
    (1) Ideal for distributed 5G deployments
    (2) Dust free
    (3) High cooling efficiency in compact space
    (4) Extend lifespan for IT equipment
    (5) Zero water consumption

(C)50kW Single Phase Immersion Cooling Solution

  • Feature:
    (1) Separated CDUs and tanks
    (2) 20U space for IT deployments
    (3) Max. cooling capacity up to 50kW indoor

  • Advantage:
    (1) No need for water chiller
    (2) Low noise level design, suitable for offices and laboratories
    (3) Cooling capacity equivalent to 5 racks

  • Benefit:
    (1) Electricity saving & decarbonization
    (2) Dust free
    (3) Low noise level
    (4) Vibration Reduction
    (5) Longer lifespan for IT gear


(D)100kW Single Phase Immersion Cooling Solution

  • Feature:
    (1) Separated CDUs and tanks
    (2) 38U space for IT deployments
    (3) Max. cooling capacity up to 100kW indoor

  • Advantage:
    (1) No need for water chiller
    (2) Low noise level design, work friendly environment in computer rooms
    (3) Cooling capacity equivalent to 10 racks

  • Benefit:
    (1) Electricity saving & decarbonization
    (2) Dust free
    (3) Low noise level
    (4) Vibration Reduction
    (5) Extend lifespan of IT equipment


Downloads

Text 3


Success Case

  • 30kW ~ 200kW Immersion Liquid Cooling Solutions
  • Cooling capacity 3.6MW ~ 100MW ----Keeping up to-----> 450MW

Market Project

  • 2018.Q3 – Present (operating 24/7 with zero failure reported)
  • Max. cooling capacity 3.6MW
  • Average annual PUE (Power Usage Effectiveness) 1.07(less 7% of electricity used for cooling)

Leading Data Center Provider
Photo credit by client public released
